Synchronous Clamp

Catalog Download Manual Download

Specifications
Dimensions
Download

Model	Eff. Piston area Extend cm²	Eff. Piston area Retract cm²	Jaw stroke (Dia.)(mm)	Clamping capacity (mm)	Max. clamping force kN(kgf)	Max. pressure MPa (kgf/cm²)	Weight (kg)
CP-20	28.27	25.13	20	150	14.4(1465)	3.5(35)	9.5
CP-30A	28.27	25.13	30	180	14.4(1465)	3.5(35)	11
CP-30	28.27	25.13	30	210	14.4(1465)	3.5(35)	12
CP-40	28.27	25.13	40	200	14.4(1465)	3.5(35)	12
CP-50	38.48	33.57	50	215	17.7(1812)	3.5(35)	18.5
CP-70	50.26	45.35	70	235	23.9(2434)	3.5(35)	30

* Subject to technical changes.

Model	A	B	B1	C	D	E(h6)	F	G max.	G min.	H	H1	J	J1	J2	K	L	M	N	P	Q	R	S	T	U	U1	U2	V	W	W1	W2	X	Y	Z
CP-20	215	88	96	53	40	18	4	249	229	75	13	94	76	83.5	M10x1.5	M10	12	M6x1	18	20	66	24	22	102	190	60	156	32	110	65	150	22	4
CP-30A	250	88	96	53	40	18	4	295	265	75	13	94	76	96	M10x1.5	M10	14	M6x1	20	24	96	24	22	102	190	60	156	20	120	65	156	22	6
CP-30	280	88	96	53	40	22	4	327	297	75	13	94	76	96	M12x1.75	M10	14	M6x1	20	24	98	24	22	102	190	60	156	23	110	65	156	22	6
CP-40	270	88	96	53	40	22	4	331	291	75	13	94	76	110	M12x1.75	M10	14	M6x1	20	24	98	24	22	102	190	60	156	25	110	65	150	22	10.5
CP-50	300	110	115	65	50	28	5	369	319	90	15	105	105	120	M12x1.75	M10	16	M8x1.25	21	28	102	30	32	105	230	85	195	29	140	80	180	30	10
CP-70	346	120	126	89	55	32	5	430	360	114	15	115	115	146	M14x2	M12	16	M8x1.25	23	28	112	30	52	120	275	95	240	42	155	90	210	34	23.5

Model	2D pdf	2D dwg	3D step
CP-20
CP-30A
CP-30
CP-40
CP-50
CP-70

Applications

Synchronous Clamps(CP-30) Applications
