Specifications
| Model | Eff. piston area cm2 | Chucking Dia. Max. (mm) | Chucking Dia. Min. (mm) | Max. clamping force kN (kgf) | Max. roller surface speed M/min. | Max. pressure bar | Clamping accuracy mm | Repeat accuracy mm | clamping weight (kg) | Weight (kg) |
| SR-02A | 19.6 | 102 | 8 | 4.59(459) | 900 | 30 | 0.02 | 0.005 | 459 | 19 |
| SR-03 | 38.5 | 152 | 12 | 10.2(1040) | 750 | 60 | 0.02 | 0.005 | 1000 | 39 |
| SR-04 | 63.5 | 245 | 30 | 15(1529) | 760 | 75 | 0.05 | 0.007 | 1500 | 98 |
Dimensions
* Subject to technical changes.
| Model | A | B | C | D | E | F | G | O | K | L (Width of rollers) | M (Diameter of rollers) | P | P1 | P2 | S | T | V |
| SR-02A | 279 | 197 | 82 | 205 | 170 | 85 | 70 | 70 | 35 | 19 | 35 | 102 | 51 | 51 | 14 | 68 | 54 |
| SR-03 | 427 | 307 | 120 | 290 | 262 | 135 | 95 | 115 | 45 | 25 | 47 | 130 | 55 | 75 | 18 | 93 | 89 |
| SR-04 | 603 | 448 | 155 | 405 | 365 | 240 | 110 | 146 | 60 | 25 | 52 | 150 | 75 | 75 | 23 | 105 | 128 |
